Hungary Pit Tilt Parking Lift Underground Parking Systems
Feature
1.Residential and commercial buildings basement garage parking solution.
2.CPT-2 pit parking system providing independent parking spaces for 2 cars (EB), 2X2 cars (DB),on one on top of the other each , the parking bay are accessed inclined (by appro x 7.5 degree).
3.Loading Capacity 2000kg.
4.Inclined lower platform with lower pit height.
5.Galvanized platform with waving plate for better parking.
6.Even in case of smaller installation heights, two cars can be parked easily on top of each other.
7.Steel cables provide additional protection against falls.
8.Powder spray coating surface treatment for indoor use hot galvanizing for outdoor use.
Specification
| Product Parameters | |
| Model No. | CPT-2/4 |
| Lifting Capacity | 2000 kg/5000lbs |
| Lifting Height | 1650 mm |
| Upper | 1650mm |
| Pit | 1700mm |
| Lock Device | Dynamic |
| Lock release | Electric auto release or manual |
| Drive Mode | Hydraulic Driven + Chain |
| Power Supply / Motor Capacity | 380V, 5.5Kw 60s |
| Parking Space | 2/4 |
| Safety Device | Anti-falling Device |
| Operation Mode | Key switch |
Drawing
Why Choose US
1. Professional car parking lift Manufacturer, More than 10 years experience. We are committed to manufacturing, innovating, customizing and installing various car parking equipment.
2. 16000+ parking experience, 100+ countries and regions.
3. Product Features: Using high quality raw material to ensure the quality
4. Good Quality: TUV, CE certified. Strictly inspecting every procedure. Professional QC team to ensure the quality.
5. Service: Professional technical support during pre-sale and after sale customized service.
6. Factory: It located in Qingdao, east coast of China, Transportation is very convenient. Daily capacity 500 sets.
